Technical Specifications of Various Solar Air Heating Systems

Parameters:

ModelSAH30 / SAH34 (Metrics)SAH30 / SAH34 (Imperial)
Panel dimensions 95 x 140 x 7.7 cm 37 X 55 X 3 Inch/s
Weight 29 kg 63lb
Fan output to 120 m3 / h to 4238 ft3 / h
Footprint absorber 1.3 m2 14 ft2
Photovoltaic performance 20 W 68 BTU
Performance max. 1000 W/ h max. 3412 BTU
Room area/space coverage 75 m2 185 m3 807 ft2 6533 ft3
Temperature rise 35-40 °C 95-104 °F
